Product Name
|
I3200-U1
|
I3200-U1
|
I3200-A1
|
|
Ink type
|
UV
|
Eco Solvent
|
Aqueous
|
|
Type
|
PrecisionCore MicroTFP printhead
|
||
|
Width*Depth*Height
|
69.1x 59.4 x 35.6 mm
|
||
|
Weight
|
82 g
|
||
|
Number of nozzle
|
3200
|
||
|
Nozzle pitch/nozzle row
|
1/300 inch
|
||
|
Nozzle rows
|
8 rows
|
||
|
Nozzle Resolution
|
300 npi /row 600 npi/2 row
|
||
|
Max. number of colour inks
|
4 colours
|
||
|
Effective print width
|
33.8 mm (1.33 inches)
|
||
|
Jetting frequency
|
43.2 kHz (Single mode)
|
||
|
21.6 kHz (Multi mode)
|
|||
|
Droplet volumes
|
5 pl (Single mode)
|
6 pl (Single mode)
|
|
|
6, 12.5 pl (Multi mode)
|
6.3,1 2.3 pl (Multi mode)
|
||
|
Viscosity range
|
5-7 mPa･s
|
3-4 mPa･s
|
|
|
Positioning Mechanism
|
Reference hole
|
||
